MMCR18 Media Converter Chassis Installation Guide
28
Note
If you need replacement screws for the blank panels and sliding
carriers, contact Allied Telesis. See “Contacting Allied Telesis” on
page 11.
Power Supply
Package
In addition to the chassis, you must have at lease one power supply unit.
1. Remove all components from the power supply package.
Note
Store the packaging material in a safe location. You must use the
original shipping material if you need to return the unit to Allied
Telesis.
2. Verify that the following components are included in your power supply
package. See Table 3 on page 29.
You must have either the AC power supply package or DC power
supply package.
18 Screws for
the blank panels
M3x4mm Phillips recessed flat-head at 120° included
angle
18 Sliding
carriers
36 Screws for
the sliding
carriers
M3x4mm Phillips recessed flat-head at 120° included
angle
Table 2. Chassis Shipment Components
Component
Name
Component
To Next Page
