47
Appendix A
Technical Specifications
Physical Specifications
Dimensions: W x H x D
439 mm x 86mm x 239 mm
(17.3 in x 3.4 in x 9.4 in)
Environmental Specifications
Operating Temperature: 0° C to 50° C (32° F to 122° F)
Storage Temperature: -15° C to 65° C (-5° F to 149° F)
Operating Humidity: 5% to 90% non-condensing
Storage Humidity: 5% to 95% non-condensing
Operating Altitude: Up to 3,048 meters (10,000 feet)
Electrical Ratings
AC Power
Power Rating: 100-240 VAC, 50/60 Hz, 2.0A
DC Power
Input Current: 40-60 VDC, 1.5A
Relay Contact Ratings (Alarm Out Connector on the Fan Unit)
AC Rating: 30Vrms, 0.5A
DC Rating: 30VDC, 1A
