Safety
2-6 Opus Operator's Manual
Footswitch label; located on the service
panel to identify the footswitch connection port
Packaging Label - attached to the system's shipping
crate
Keep Dry - This symbol indicates that the crate must be
protected from excessive humidity and accordingly must be
stored under cover. If particularly large or bulky packages
cannot be stored in a warehouse or shed, they must be
carefully covered with tarpaulins
Fragile - Cargo marked with this symbol should be handled
carefully and should never be tipped over or slung
Top - The package must be always transported, handled and
stored in such way that the arrows always point upwards.
Rolling, Swinging, severe tipping or tumbling, or other such
handling must be avoided.
The cargo need not, however, be stored “on top”.
Temperature Limitations - The symbol provides the
storage and transport temperature range. In this case, the
temperature limit is between high +50 °C and low 0 °C.
Humidity Limitations - The symbol provides the storage
and transport humidity range. In this case, the humidity
limit is between 60% high and 10% low.
Air Pressure Limitations - The symbol provides the
storage and transport air pressure limit. In this case,
indicating a low 90 kPa and a high 110 kPa.
