Alpha CXPS-C - Features

9400001-J1 Rev F
10
Table B — Related Components
Cordex HP 4kW rectier
See the Cordex HP 4kW rectier datasheet for more detailed information.
Cordex HP 12kW rectier
See the Cordex HP 12kW rectier datasheet for more detailed information.
System level alarms/controls
Alarms/control parameters are user-programmable through built-in digital supervisory unit.
See CXC HP datasheet for detailed information on alarms and controls.
Indicators:
LCD with touch screen
System OK (green LED)
System minor alarm (yellow LED)
System major alarm (red LED)
Load disconnect:
Panel based.
2000A per TPL fuse/Bolt-in breaker panel
600A pre plug-in bullet TLS/TPS fuse/CB panel
Alarm connections: 0.34 to 2.5 mm
2
(14 to 22AWG)
Smart peripheral modules
Shunt multiplexer 6 shunt inputs per module
External return bar
Mounting 2" Auxiliary framing (customer supplied)
Termination
With 3 horizontal bars:
202 sets of 1/2" holes on 1 3/4" centers or
202 sets of 3/8" holes on 1" centers
Unit capacity per bay 4000A
Ultimate capacity 12,000A (3 bay limit)
Table C — Distribution, Panels
Panel Type/
Busbar
Quantity/Rating Max Rating
per Panel
Output Termination
TPL Fuses 61 to 800A (up to 24
per distribution bay)
2000A 2 hole 1/2" dia. on 1 3/4" centers or
2 hole 3/8" dia. on 1" centers
allows for dual cable landing back to back
Bolt-in breakers 1 pole up to 250A
2 pole 300 to 400A
3 pole 500 to 700A
4 pole 800A
5 pole 1000A
6 pole 1200A
2000A 2 hole 3/8" dia. on 1" center and 1/2" dia. on 1 3/4"
center
12x 1 Position 2 hole, 3/8" dia. on 1" center only
Plug-in bullet
breakers
1 pole up to 100A
2 pole 110 to 200A
3 pole 225 to 300A
600A 1 pole: 2 hole 1/4" dia. on 5/8" centers
2 and 3 pole: 2 hole, 3/8" dia. on 1 centers
(100A and 125A breakers/fuses need one breaker
space)
Plug-in TPS/TLS
fuse holders
Up to 125A, 18 per panel 600A 2 hole 1/4" dia. on 3/8" centers
