Alpha CXPS-C - Page 14

119400001-J1 Rev F
Table D — Distribution, Busbars
Number of negative landings
for batteries (rectier side of
the shunt)
Single power bay: 11 X 1/2" on 1 3/4" centers or 24 x 3/8" on 1" centers
Each additional power bay: 14 X 1/2" on 1 3/4" centers or 14 x 3/8" on 1" centers
Number of landings on the
load side of the shunt to feed
unfused power to remote
distribution
Single distribution bay: 14 X 1/2" on 1 3/4" centers or 11 x 3/8" on 1" centers
Each additional power bay: 14 X 1/2" on 1 3/4" centers or 14 x 3/8" on 1" centers
Internal return bar Overhead bus ground, 24 sets of 2 hole, 1/2" dia. on 1 3/4" centers or 3/8" dia. on 1"
centers (basic one power plus one distribution bay); 14 additional sets per additional
rectier or distribution bay
