Alpitronic Hypercharger HYC 150 User Manual

hypercharger - Operation Instructions and Installation Guide
Hardware
Version 2-2
Page 100 of 105
11 Technical specifications
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by alpitronic Srl
HYC_300
Parameter
Nominal value
Operating voltage
400 Vac +N +PE (± 10 %)
Frequency
50 Hz (± 5 %)
Nominal current
max. 500 A
Connection terminals cross section
connecting bolt 2x12mm
Rated peak withstand current I
pk
17 kA (peak)
Rated short-time withstand current I
cw
4 kA (rms)
Table 29: Electrical connection for HYC_300
HYC_300_f
Parameter
Nominal value
Operating voltage
400 Vac +N +PE (± 10 %)
Frequency
50 Hz (± 5 %)
Nominal current
max. 500 A
Connection terminals cross section
connecting bolt 2x12mm
Prospective short circuit current I
p
48 kA (rms)
Rated short-time withstand current I
cw
4 kA (rms)
Table 30: Electrical connection for HYC_300_f
The hypercharger is designed for the direct connection to the mains supply.
Standby power consumption
The values from Table 31 refer to a 400 V supply network. Depending on the number of
cable coolers, CTRL_IO boards and illuminated plug holders, the active power can
additionally increase by up to 10 W.
Configuration
Quantity
of
Stacks
Stack
Version
Reactive
power
Active power
without
energy saving
mode
Active power
with energy
saving mode
HYC_150
V3 / V4
1
V4
3,4 kvar
65 W
45 W
2
V4
4,9 kvar
100 W
60 W
1
V5
1,8 kvar
65 W
45 W
2
V5
1,8 kvar
100 W
60 W
HYC_300 V3
1
V4
4,3 kvar
65 W
45 W
2
V4
5,8 kvar
100 W
60 W
3
V4
7,3 kvar
135 W
75 W
4
V4
8,8 kvar
170 W
90 W
1
V5
2,8 kvar
65 W
45 W
2
V5
2,8 kvar
100 W
60 W
3
V5
2,8 kvar
135 W
75 W
4
V5
2,8 kvar
170 W
90 W
