Hardware
Version 2-2
Page 38 of 105
2 Product description
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by alpitronic Srl
The following table describes the single components highlighted in the figures above:
Identifier
Description
-BE1
DC-meter for DC-outlet 1
-BE2
DC-meter for DC-outlet 2 (optional)
-BE3
DC-meter for DC-outlet 3 (optional)
-BE4
DC-meter for DC-outlet 4 (optional)
-FC1
DC-outlet 1 fuses
-FC2
DC-outlet 2 fuses (optional)
-FC3
DC-outlet 3 fuses (optional)
-FC4
DC-outlet 4 fuses (optional)
-KF3
CTRL_IO control board
-QB2.1, -QB2.2
DC-outlet 1 contactors
-QB3.1, -QB3.2
DC-outlet 2 contactors (optional)
-QB4.1, -QB4.2
DC-outlet 3 contactors (optional)
-QB5.1, -QB5.2
DC-outlet 4 contactors (optional)
-QB6.1, -QB6.2
-QB7.1, -QB7.2
-QB8.1, -QB8.2
DC-contactors to switch Power-Stacks in parallel mode
-XD3.1
DC-busbar - pole for vehicle cable connection XD7 (DC-outlet 1)
-XD3.2
DC-busbar + pole for vehicle cable connection XD7 (DC-outlet 1)
-XD4.1
DC-busbar - pole for vehicle cable connection XD8 (DC-outlet 2)
-XD4.2
DC-busbar + pole for vehicle cable connection XD8 (DC-outlet 2)
-XD5.1
DC-busbar - pole for vehicle cable connection XD9 (DC-outlet 3)
-XD5.2
DC-busbar + pole for vehicle cable connection XD9 (DC-outlet 3)
XD6.1
DC-busbar - pole for vehicle cable connection XD10 (DC-outlet 4)
XD6.2
DC-busbar + pole for vehicle cable connection XD10 (DC-outlet 4)
Table 14: DC output switchgear components for hypercharger HYC_300
