Alpitronic Hypercharger HYC 150 User Manual

hypercharger - Operation Instructions and Installation Guide
Hardware
Version 2-2
Page 16 of 105
2 Product description
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by alpitronic Srl
The HYC_300 can be equipped with one, two, three or four Power-Stacks and with up to 3
DC charging cables and a 22 kW AC charging socket or AC cable:
Figure 2: Configuration HYC_300
Remark
The order of the charging points (with view of the charging cable door)
is always from left to right, AC - if available - is in last place.
Figure 3: Order of charging points HYC_150 and HYC_300
Remark
Customs tariff number of the hypercharger: 85044055
