ELECTRICAL CONNECTIONS
BLOCK CONTACT DESCRIPTION
9
LCG * Barrier LED lamp power supply output (green light)
LCR * Barrier LED lamp power supply output (red light)
+24V * +24 V DC power supply output to barrier LED lamp
10
GND Antenna Shield Conductor Input
ANT * Antenna signal conductor input
11
B
Data transfer contacts in synchronized
operation of two boom barriers
Section ‘7.2 Setting operation
parameters’ P9–F1.
Fig. 42. When connecting, use a data
cable (twisted pair cable,
e.g.: 2×2×0.5 cat5) up to 20 m long.
A
GND Common contact
12
+5V *
Connection contacts of the barrier motor encoderPULS *
GND *
OP.L * End position switch OPEN input with normally closed contact (NC)
GND * Common contact of end position switches
CL.L * End position switch CLOSED input with normally closed contact (NC)
13
~24 *
Inputs for secondary coil leads of control unit transformer~12 *
~0 *
M2 *
Outputs for connection of the barrier motor leads
M1 *
* Connections are performed by manufacturer on delivery.
