PRODUCT DESCRIPTION
2. PRODUCT DESCRIPTION
BV-5-868 electromechanical barrier is designed to automatically restrict entry/ exit of vehicles to/
from acertain territory. When equipped with aRBN8 boom prole, the roadway width is limited to
5m. When equipped with aRBN6-K(optional) boom prole, the roadway width is limited to 6m.
The barrier is equipped with aDC motor with an encoder, agearbox, abalancing spring, asystem
of limit switches, an electronic control unit with an integrated radio receiver, and aLED signal
lamp. The barrier has aself-locking feature (when the barrier is locked, the boom cannot be
moved manually without damaging the barrier, boom or mounting). The barrier is powered from
~230 V/50 Hz mains. In case the mains power supply is temporarily unavailable, the manual
unlocking feature integrated in the barrier will allow moving the boom manually, or the barrier
may be powered by aspecial battery pack (optional).
2.1 SCOPE OF DELIVERY
The scope of delivery of the barrier is shown in Fig. 1.
Y
The boom kit (item 12, Fig.1) depends on the type of boom prole and roadway width. The boom
prole, as well as prole length and components (damping devices, etc.) are to be agreed upon
when ordering the barrier.
Y
The barrier cabinet kit contains components for mounting the RBN8 boom prole.
Once you have received the barrier, make sure that the package is complete and the components
are free of visible damage. If any inconsistencies are found, please contact the supplier.
2.2 TECHNICAL SPECIFICATIONS
Table 1
DESCRIPTION VALUE
Maximum torque 230Nm*
Eective boom length (L
1
, Fig.2–4) 3–5 m (optional up to 6 m)
Power supply 230V (±10%) / 50Hz
Maximum power consumption 100 W*
Maximum power consumption in standby mode 10 W
Intensity of service 250cycles / h*
Maximum opening time 6s*
Rated electric motor voltage 24 V
Radio control
868.35±0.15 MHz / dynamic code /
max. 250 remote control
Protection class I
Protection degree IP54
Working temperature range −30…+65 °
Barrier weight (gross) 60 kg
* The above characteristics are valid for ambient temperatures +20° (±5°) in case of compliance with assembly
and operation rules.
