BOOM BARRIER BV58683030
INDICATION
8. INDICATION
Table 19 — LEDs 14 (see Fig.37)
LED INDICATION PURPOSE ON OFF
LR
Radio control command (LED turns red if the remote is
not recorded or the button of the remote is not assigned
a control command / green if the button of the recorded
remote control is assigned a control command)
sent not sent
LOP
Open command
(OP input, terminal block 4)
LCL
Close command
(CL input, terminal block 4)
LSBS
Open, stop, close command
(SBS input, terminal block 4)
LCOV
Barrier door position switch
(CVR input, terminal block 4)
activated failed
LALR
Command to ALR input
(terminal block 4)
sent not sent
LS
STOP safety device
(S input, terminal block 4)
activated failed
LPH2
Safety device photocells
(PH2 input, terminal block 4)
activated failed
LPH1
Safety device photocells
(PH1 input, terminal block 4)
LCL.L
End position switch CLOSED
(CL.L input, terminal block 12)
LOP.L
End position switch OPENED
(OP.L input, terminal block 12)
LLK1
Terminal block 7 outputs status enabled in settings
( subsection ‘7.2. Setting operation parameters’ P3–F6).
LED light is o when the terminals are in normal condition
and is ON when the terminals are activated.
