BOOM BARRIER BV58681616
SETUP
REMOTE CONTROL COMMANDS DESCRIPTION
F1F5 ITEMS
CONTROL COMMAND VALUE
STOP Stop operation STOP 04
LIGHTING
Switch ON, or OFF, or ON / OFF
during conguration of outputs on
terminal blocks 5–8 (Table 4) to op-
erate the lighting (settings P3–F4…
F7, Table 15).
Automatic disabling (operation
time) for the lighting is set by P8–F4
settings
LIGHTING (ON) 08
LIGHTING (OFF) 09
LIGHTING (ON / OFF) 10
LOAD
Switch ON, or OFF, or ON / OFF
during conguration of outputs
on terminal blocks 5–8 (Table 4) to
control external load 1 or 2
(settings P3–F4…F7, Table 15).
Automatic disabling (operation
time) of the load is set by P8–F7
(LOAD1) and P8–F8 (LOAD2)
settings
LOAD 1 (ON) 11
LOAD 1 (OFF) 12
LOAD 1 (ON / OFF) 13
LOAD 2 (ON) 14
LOAD 2 (OFF) 15
LOAD 2 (ON / OFF) 16
