SETUP
Table 16
VALUE DESCRIPTION
01
Signal lamp. Will be operated by movement and during motion delay time (setting P8–F2,
Table 15).
Fig. 43 — example of signal lamp connection
02
Lighting lamp. Operated by movement and during some time after the movement stops
(setting P8–F3, Table 15). When there is no movement, the lighting lamp can be operated
by a command from remote control (control commands LIGHTING, Table 6) with actuation
time setting (setting P8–F4, Table 15).
Fig.43 — example of lighting lamp connection
03
One-way trac light (full opening indication). Operates after full opening.
Fig.44 — example of trac light connection
04
No full closing. Operates always, except full closing in standby mode.
Fig.45 — example of trac light connection using the second terminal block (second relay)
for trac light disconnection (red light) when fully closed
05
EXIT trac light for two-way signalization. Operates after full
opening by control commands SBS EXIT and OPEN EXIT
Sub-section
‘7.5.Two-Way Trac
Signalization provides
an implementation
example’
06
ENTRY trac light for two-way signalization. Operates after
full opening by control commands SBS ENTRY and OPEN ENTRY
07
No full opening. The action will always take place except when fully closed in standby
mode.
Fig.47 — example of two trac lights connection using the third terminal block (third relay)
for trac lights (red) disconnection when fully closed
08 OPEN end position. Operation in fully open position
09 CLOSED end position. Operation in fully closed position
10 Signal after OPEN command. Operation in 1s after any OPEN control command
11 Signal after CLOSE command. Operation in 1s after any CLOSE control command
12
Signal after control command. Operation in 1s after any control command (OPEN, CLOSE,
STOP, LIGHTING and others)
13
LOAD 1: will be activated by remote control command (LOAD 1 control command, Table 6)
during the set activation time (P8–F7 setting, Table 15)
14
LOAD 2: will be activated by remote control command (LOAD 2 control command, Table 6)
during the set activation time (P8–F8 setting, Table 15)
15
Electromagnetic lock. Operates in fully closed position after the open control command
is sent. Operation starts at the beginning of the set movement delay time (P7—F6 setting,
Table 15) and continues until returns to the full closing position.
Fig. 50 — xample of an electromagnetic lock connection
16
Electromechanical lock. Operates in fully closed position after the open control command
is sent. Operation starts at the beginning of the set movement delay time (P7–F6 setting,
Table 15) and continues operating until closed end position switch is o (or during 2 s).
Fig.49 — xample of an electromechanical lock connection
