Layout and function
14
AMALOG BAH0017.6 08.19
4.3 Operation with seed drills
The AmaLog+
 measures the covered part area [ha].
 stores the cultivated total area [ha].
 indicates the forward speed [km/h].
 controls the tramline control and the tramline marker
 indicates the position of the hydraulically operated track markers
 initiates an alarm when the set minimum quantity is reached in the tank (fill level sensor re-
quired).
4.3.1 Operation with cam wheel seed drill
For seed drills with tramline control, AmaLog+
monitors the drive of the lay shaft (Fig. 4/1).
Fig. 4
