Layout and function
AMALOG BAH0017.6 08.19
19
4.6 Creation of tramlines
As described in the operating manual for the seed drill, the tramline control allows the creation of tram-
lines at pre-selected intervals on the field.
When creating the tramlines
the tramline counter shows the number "0" on the control terminal
the tramline coulters do not deposit any seeds on the ground.
The required tramline rhythm is obtained from the desired tramline spacing and the seed drill working
width (see seed drill operating manual). All adjustable tramline rhythms can be found in the section
"Table for adjustable tramline rhythms", Seite 39. The tramline rhythm must be entered on the control
terminal (see section "Displaying / altering the tramline rhythm", Seite 26).
The control terminal counts up the tramlines in the tramline counter
after actuation of the track markers, e.g. before turning at the end of the field
after the machine is raised (without track markers), e.g. for turning at the end of the field.
The tramline counter can be blocked (see section "Block the tramline counter", Seite 31)
before raising the track marker, e.g. before an obstacle
before machine standstill (without track markers), e.g. in the event of a work interruption on the
field.
Before resuming work
activate the tramline counter
check the tramline counter display.
