Layout and function
20
AMALOG BAH0017.6 08.19
The creation of tramlines is shown in Figure (Fig. 10) using various examples:
A = Working width of the seed drill
B = Tramline spacing
(= working width fertiliser spreader/field sprayer)
C = Tramline rhythm (entered on the control terminal)
D = Tramline counter (during operation, the field passes are numbered consecutively and displayed on
the control terminal).
