Version 1.4 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 15
transmitter.
Figure 22 displays all four switches in the OFF position (factory default setting).
Figure 22
Channel Number: The WS-50 supports up to eight transmitters. To set each channel number (the
default is Channel 1), change Dip Switches 1, 2 and 3, as referenced in Table 1.
Temperature Units of Measure: To change the transmitter display units of measure (°F vs. °C), change
Dip Switch 4, as referenced in Table 1.
Table 1
Insert two AAA batteries.
After inserting the batteries, the remote sensor LED indicator will light for 4 seconds, and then
flash once per 60 seconds thereafter. Each time it flashes, the sensor is transmitting data.
Verify the correct channel number (CH) and temperature units of measure (°F vs. °C) are on the
display, as shown in Figure 23.
