Version 1.4 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 27
Figure 41
Note: The sensors have the capability of being placed inside or outside the refrigerator/freezer, but
it is recommended you install it outside. This will extend the battery life, the sensor life, and improve
wireless communication range.
Note: Make sure that the refrigerator surface is smooth and clean, so that suction cups will not fall
off. It is recommended to wet the surface of the suction cup first to improve the seal.
Wall Mounting
The remote sensor can be mounted to a wall or horizontal surface to measure any temperature medium,
including air, water, and soil.
Use a screw or nail (not included) to affix the remote sensor to the wall, as shown in Figure 42.
Note: If measuring outside air temperature, we recommend mounting the sensor in the shade, on the
north side of the house or structure to avoid radiant heat transfer.
