VCU118 Board User Guide 104
UG1224 (v1.5) March 15, 2023
Chapter3: Board Component Descriptions
J22 Sections L/M Connections to FPGA U1
L1 NC
M2 FMCP_HSPC_DP23_M2C_P LVDS AU45
L4 FMCP_HSPC_GBTCLK4_M2C_P(5) LVDS R40 M3 FMCP_HSPC_DP23_M2C_N LVDS AU46
L5 FMCP_HSPC_GBTCLK4_M2C_N(5) LVDS R41 M6 FMCP_HSPC_DP22_M2C_P LVDS AW45
L8 FMCP_HSPC_GBTCLK3_M2C_P(5) LVDS AB38 M7 FMCP_HSPC_DP22_M2C_N LVDS AW46
L9 FMCP_HSPC_GBTCLK3_M2C_N(5) LVDS AB39 M10 FMCP_HSPC_DP21_M2C_P LVDS BA45
L12 FMCP_HSPC_GBTCLK2_M2C_P(5) LVDS AF38 M11 FMCP_HSPC_DP21_M2C_N LVDS BA46
L13 FMCP_HSPC_GBTCLK2_M2C_N(5) LVDS AF39 M14 FMCP_HSPC_DP20_M2C_P LVDS BC45
L16 FMCP_HSPC_SYNC_C2M_P LVDS AN34 M15 FMCP_HSPC_DP20_M2C_N LVDS BC46
L17 FMCP_HSPC_SYNC_C2M_N LVDS AN35 M18 FMCP_HSPC_DP14_C2M_P LVDS W40
L20 FMCP_HSPC_REFCLK_C2M_P LVDS AN33 M19 FMCP_HSPC_DP14_C2M _ N L V D S W 4 1
L21 FMCP_HSPC_REFCLK_C2M_N LVDS AP33 M22 FMCP_HSPC_DP15_C2M_P LVDS U40
L24 FMCP_HSPC_REFCLK_M2C_P LVDS AK34 M23 FMCP_HSPC_DP15_C2M_N LVDS U41
L25 FMCP_HSPC_REFCLK_M2C_N LVDS AL34 M26 FMCP_HSPC_DP16_C2M_P LVDS H42
L28 FMCP_HSPC_SYNC_M2C_P LVDS AM36 M27 FMCP_HSPC_DP16_C2M_N LVDS H43
L29 FMCP_HSPC_SYNC_M2C_N LVDS AN36 M30 FMCP_HSPC_DP17_C2M _ P LV D S F 4 2
L32 NC M31 FMCP_HSPC_DP17_C2M_N LVDS F43
L33 NC M34 FMCP_HSPC_DP18_C2M_P LVDS D42
L36 VCC12_SW M35 FMCP_HSPC_DP18_C2M_N LVDS D43
L37 VCC12_SW M38 FMCP_HSPC_DP19_C2M_P LVDS B42
L40 VCC12_SW M39 FMCP_HSPC_DP19_C2M_N LVDS B43
Table3‐32 : J22 VITA 57.4 FMPC HSPC Connections (Cont’d)
J22
FMCP
HSPC
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1) Pin
J22
FMCP
HSPC
Pin
Schematic Net Name I/O Standard
FPGA
(U1) Pin
