VCU118 Board User Guide 105
UG1224 (v1.5) March 15, 2023
Chapter3: Board Component Descriptions
J22 Sections Y/Z Connections to FPGA U1
Y2 FMCP_HSPC_DP23_C2M_P LVDS AV42
Z1 FMCP_HSPC_Z_PRSNT_M2C_B(4) LVCMOS18 AM29
Y3 FMCP_HSPC_DP23_C2M_N LVDS AV43 Z4 FMCP_HSPC_DP22_C2M_P LVDS AY42
Y6 FMCP_HSPC_DP21_C2M_P LVDS BB42 Z5 FMCP_HSPC_DP22_C2M_N LVDS AY43
Y7 FMCP_HSPC_DP21_C2M_N LVDS BB43 Z8 FMCP_HSPC_DP20_C2M_P LVDS BD42
Y10 FMCP_HSPC_DP10_M2C_P LVDS AE45 Z9 FMCP_HSPC_DP20_C2M_N LVDS BD43
Y11 FMCP_HSPC_DP10_M2C_N LVDS AE46 Z12 FMCP_HSPC_DP11_M2C_P LVDS AD43
Y14 FMCP_HSPC_DP12_M2C_P LVDS AC45 Z13 FMCP_HSPC_DP11_M2C_N LVDS AD44
Y15 FMCP_HSPC_DP12_M2C_N LVDS AC46 Z16 FMCP_HSPC_DP13_M2C_P LVDS AB43
Y18 FMCP_HSPC_DP14_M2C_P LVDS AA45 Z17 FMCP_HSPC_DP13_M2C_N LVDS AB44
Y19 FMCP_HSPC_DP14_M2C_N LVDS AA46 Z20 FMCP_HSPC_GBTCLK5_M2C_P(5) LVDS AN40
Y22 FMCP_HSPC_DP15_M2C_P LVDS Y43 Z21 FMCP_HSPC_GBTCLK5_M2C_N (5) LVDS AN41
Y23 FMCP_HSPC_DP15_M2C_N LVDS Y44 Z24 FMCP_HSPC_DP10_C2M_P LVDS AG40
Y26 FMCP_HSPC_DP11_C2M_P LVDS AE40 Z25 FMCP_HSPC_DP10_C2M_N LVDS AG41
Y27 FMCP_HSPC_DP11_C2M_N LVDS AE41 Z28 FMCP_HSPC_DP12_C2M_P LVDS AC40
Y30 FMCP_HSPC_DP13_C2M_P LVDS AA40 Z29 FMCP_HSPC_DP12_C2M_N LVDS AC41
Y31 FMCP_HSPC_DP13_C2M_N LVDS AA41 Z32 FMCP_HSPC_DP16_M2C_P LVDS L45
Y34 FMCP_HSPC_DP17_M2C_P LVDS J45 Z33 FMCP_HSPC_DP16_M2C_N LVDS L46
Y35 FMCP_HSPC_DP17_M2C_N LVDS J46 Z36 FMCP_HSPC_DP18_M2C_P LVDS G45
Y38 FMCP_HSPC_DP19_M2C_P LVDS E45 Z37 FMCP_HSPC_DP18_M2C_N LVDS G46
Y39 FMCP_HSPC_DP19_M2C_N LVDS E46 Z40 UTIL_3V3
Notes:
1. VADJ_1V8_PGOOD is level-shifted by U44 and is connected to FPGA pin U1.AK35.
2. FMCP_HSPC_PG_M2C is level-shifted by U44 and is connected to FPGA pin U1.AM34.
3. FMCP_HSPC_H_PRSNT_M2C_B is level-shifted by U44 and is connected to FPGA pin U1.AM33.
4. FMCP_HSPC_Z_PRSNT_M2C_B is level-shifted by U44 and is connected to FPGA pin U1.AM29.
5. FMCP_HSPC_GBTCLKn_M2C_P/N are series capacitor coupled, the nets connected to FPGA U1 are FMCP_HSPC_GBTCLKn_M2C_C_P/N.
Table3‐32 : J22 VITA 57.4 FMPC HSPC Connections (Cont’d)
J22
FMCP
HSPC
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1) Pin
J22
FMCP
HSPC
Pin
Schematic Net Name I/O Standard
FPGA
(U1) Pin
