VCU118 Board User Guide 25
UG1224 (v1.5) March 15, 2023
Chapter3: Board Component Descriptions
F24 DDR4_C1_DQ62 POD12_DCI D3 DQU6 U63
F23 DDR4_C1_DQ63 POD12_DCI D7 DQU7 U63
M20 DDR4_C1_DQS6_T DIFF_POD12_DCI G3 DQSL_T U63
L20 DDR4_C1_DQS6_C DIFF_POD12_DCI F3 DQSL_C U63
H24 DDR4_C1_DQS7_T DIFF_POD12_DCI B7 DQSU_T U63
G23 DDR4_C1_DQS7_C DIFF_POD12_DCI A7 DQSU_C U63
L23 DDR4_C1_DM6 POD12_DCI E7 DML_B/DBIL_B U63
G22 DDR4_C1_DM7 POD12_DCI E2 DMU_B/DBIU_B U63
A24 DDR4_C1_DQ64 POD12_DCI G2 DQL0 U64
A23 DDR4_C1_DQ65 POD12_DCI F7 DQL1 U64
C24 DDR4_C1_DQ66 POD12_DCI H3 DQL2 U64
C23 DDR4_C1_DQ67 POD12_DCI H7 DQL3 U64
B23 DDR4_C1_DQ68 POD12_DCI H2 DQL4 U64
B22 DDR4_C1_DQ69 POD12_DCI H8 DQL5 U64
B21 DDR4_C1_DQ70 POD12_DCI J3 DQL6 U64
A21 DDR4_C1_DQ71 POD12_DCI J7 DQL7 U64
D7 DDR4_C1_DQ72 POD12_DCI A3 DQU0 U64
C7 DDR4_C1_DQ73 POD12_DCI B8 DQU1 U64
B8 DDR4_C1_DQ74 POD12_DCI C3 DQU2 U64
B7 DDR4_C1_DQ75 POD12_DCI C7 DQU3 U64
C10 DDR4_C1_DQ76 POD12_DCI C2 DQU4 U64
B10 DDR4_C1_DQ77 POD12_DCI C8 DQU5 U64
B11 DDR4_C1_DQ78 POD12_DCI D3 DQU6 U64
A11 DDR4_C1_DQ79 POD12_DCI D7 DQU7 U64
D22 DDR4_C1_DQS8_T DIFF_POD12_DCI G3 DQSL_T U64
C22 DDR4_C1_DQS8_C DIFF_POD12_DCI F3 DQSL_C U64
A9 DDR4_C1_DQS9_T DIFF_POD12_DCI B7 DQSU_T U64
A8 DDR4_C1_DQS9_C DIFF_POD12_DCI A7 DQSU_C U64
E24 DDR4_C1_DM8 POD12_DCI E7 DML_B/DBIL_B U64
C9 DDR4_C1_DM9 POD12_DCI E2 DMU_B/DBIU_B U64
D14 DDR4_C1_A0 SSTL12_DCI P3 A0 U60-U64
B15 DDR4_C1_A1 SSTL12_DCI P7 A1 U60-U64
B16 DDR4_C1_A2 SSTL12_DCI R3 A2 U60-U64
C14 DDR4_C1_A3 SSTL12_DCI N7 A3 U60-U64
Table3‐2: DDR4 Memory 80‐bit I/F C1 to FPGA U1 Banks 71, 72, and 73 (Cont’d)
FPGA (U1)
Pin
Schematic Net Name I/O Standard
Component Memory
Pin # Pin Name Ref. Des.
