Chapter3: Board Component Descriptions
AT30 DDR4_C2_DQ27 POD12_DCI C7 DQU3 U136
AP30 DDR4_C2_DQ28 POD12_DCI C2 DQU4 U136
AR30 DDR4_C2_DQ29 POD12_DCI C8 DQU5 U136
AN30 DDR4_C2_DQ30 POD12_DCI D3 DQU6 U136
AN31 DDR4_C2_DQ31 POD12_DCI D7 DQU7 U136
AU29 DDR4_C2_DQS2_T DIFF_POD12_DCI G3 DQSL_C U136
AV29 DDR4_C2_DQS2_C DIFF_POD12_DCI F3 DQSL_T U136
AP31 DDR4_C2_DQS3_T DIFF_POD12_DCI B7 DQSU_C U136
AP32 DDR4_C2_DQS3_C DIFF_POD12_DCI A7 DQSU_T U136
AV33 DDR4_C2_DM2 POD12_DCI E7 DML_B/DBIL_B U136
AR32 DDR4_C2_DM3 POD12_DCI E2 DMU_B/DBIU_B U136
BE34 DDR4_C2_DQ32 POD12_DCI G2 DQL0 U137
BF34 DDR4_C2_DQ33 POD12_DCI F7 DQL1 U137
BC35 DDR4_C2_DQ34 POD12_DCI H3 DQL2 U137
BC36 DDR4_C2_DQ35 POD12_DCI H7 DQL3 U137
BD36 DDR4_C2_DQ36 POD12_DCI H2 DQL4 U137
BE37 DDR4_C2_DQ37 POD12_DCI H8 DQL5 U137
BF36 DDR4_C2_DQ38 POD12_DCI J3 DQL6 U137
BF37 DDR4_C2_DQ39 POD12_DCI J7 DQL7 U137
BD37 DDR4_C2_DQ40 POD12_DCI A3 DQU0 U137
BE38 DDR4_C2_DQ41 POD12_DCI B8 DQU1 U137
BC39 DDR4_C2_DQ42 POD12_DCI C3 DQU2 U137
BD40 DDR4_C2_DQ43 POD12_DCI C7 DQU3 U137
BB38 DDR4_C2_DQ44 POD12_DCI C2 DQU4 U137
BB39 DDR4_C2_DQ45 POD12_DCI C8 DQU5 U137
BC38 DDR4_C2_DQ46 POD12_DCI D3 DQU6 U137
BD38 DDR4_C2_DQ47 POD12_DCI D7 DQU7 U137
BE35 DDR4_C2_DQS4_T DIFF_POD12_DCI G3 DQSL_T U137
BF35 DDR4_C2_DQS4_C DIFF_POD12_DCI F3 DQSL_C U137
BE39 DDR4_C2_DQS5_T DIFF_POD12_DCI B7 DQSU_T U137
BF39 DDR4_C2_DQS5_C DIFF_POD12_DCI A7 DQSU_C U137
BC34 DDR4_C2_DM4 POD12_DCI E7 DML_B/DBIL_B U137
BE40 DDR4_C2_DM5 POD12_DCI E2 DMU_B/DBIU_B U137
BB36 DDR4_C2_DQ48 POD12_DCI G2 DQL0 U138
Table3‐3: DDR4 Memory 80‐bit I/F C2 to FPGA U1 Banks 40, 41, and 42 (Cont’d)
FPGA (U1)
Pin
Schematic Net Name I/O Standard
Component Memory
Pin # Pin Name Ref. Des.
