Chapter3: Board Component Descriptions
BB37 DDR4_C2_DQ49 POD12_DCI F7 DQL1 U138
BA39 DDR4_C2_DQ50 POD12_DCI H3 DQL2 U138
BA40 DDR4_C2_DQ51 POD12_DCI H7 DQL3 U138
AW40 DDR4_C2_DQ52 POD12_DCI H2 DQL4 U138
AY40 DDR4_C2_DQ53 POD12_DCI H8 DQL5 U138
AY38 DDR4_C2_DQ54 POD12_DCI J3 DQL6 U138
AY39 DDR4_C2_DQ55 POD12_DCI J7 DQL7 U138
AW35 DDR4_C2_DQ56 POD12_DCI A3 DQU0 U138
AW36 DDR4_C2_DQ57 POD12_DCI B8 DQU1 U138
AU40 DDR4_C2_DQ58 POD12_DCI C3 DQU2 U138
AV40 DDR4_C2_DQ59 POD12_DCI C7 DQU3 U138
AU38 DDR4_C2_DQ60 POD12_DCI C2 DQU4 U138
AU39 DDR4_C2_DQ61 POD12_DCI C8 DQU5 U138
AV38 DDR4_C2_DQ62 POD12_DCI D3 DQU6 U138
AV39 DDR4_C2_DQ63 POD12_DCI D7 DQU7 U138
BA35 DDR4_C2_DQS6_T DIFF_POD12_DCI G3 DQSL_C U138
BA36 DDR4_C2_DQS6_C DIFF_POD12_DCI F3 DQSL_T U138
AW37 DDR4_C2_DQS7_T DIFF_POD12_DCI B7 DQSU_C U138
AW38 DDR4_C2_DQS7_C DIFF_POD12_DCI A7 DQSU_T U138
AY37 DDR4_C2_DM6 POD12_DCI E7 DML_B/DBIL_B U138
AV35 DDR4_C2_DM7 POD12_DCI E2 DMU_B/DBIU_B U138
BF26 DDR4_C2_DQ64 POD12_DCI G2 DQL0 U139
BF27 DDR4_C2_DQ65 POD12_DCI F7 DQL1 U139
BD28 DDR4_C2_DQ66 POD12_DCI H3 DQL2 U139
BE28 DDR4_C2_DQ67 POD12_DCI H7 DQL3 U139
BD27 DDR4_C2_DQ68 POD12_DCI H2 DQL4 U139
BE27 DDR4_C2_DQ69 POD12_DCI H8 DQL5 U139
BD25 DDR4_C2_DQ70 POD12_DCI J3 DQL6 U139
BD26 DDR4_C2_DQ71 POD12_DCI J7 DQL7 U139
BC25 DDR4_C2_DQ72 POD12_DCI A3 DQU0 U139
BC26 DDR4_C2_DQ73 POD12_DCI B8 DQU1 U139
BB28 DDR4_C2_DQ74 POD12_DCI C3 DQU2 U139
BC28 DDR4_C2_DQ75 POD12_DCI C7 DQU3 U139
AY27 DDR4_C2_DQ76 POD12_DCI C2 DQU4 U139
Table3‐3: DDR4 Memory 80‐bit I/F C2 to FPGA U1 Banks 40, 41, and 42 (Cont’d)
FPGA (U1)
Pin
Schematic Net Name I/O Standard
Component Memory
Pin # Pin Name Ref. Des.
