Ametek 3050-DO

Set Dryer Production Code
Click to enter the Dryer Production Code for the Dryer that is installed in
the analyzer. Click OK to accept.
You must enter a new Dryer code each time you replace the Dryer.
Set Moisture Generator Production Code
Click to enter the Moisture Generator Production Code. Click OK to ac-
cept.
Set Clock
Click Set Clock to synchronize the analyzer and PC clocks. The Time Syn-
chronization box opens with the PC time and date and the analyzer time
and date. Click Synchronize to set the time, or click Cancel to close the
box.
Figure 3-6.2.
Dryer Production Code entry
dialog box.
Figure 3-6.3.
Moisture Generator Production
Code entry dialog box.
Figure 3-6.4.
Time Synchronization dialog
box.
PN 305725901, Rev YF
Controller/Interface | 3-15
