Pre-Installation Requirements
Storage Prior to Installation
If the analyzer is stored for any period of time prior to installation, it must
be housed in a temperature-controlled environment where it is not sub-
ject to dripping or splashing liquids, corrosive gases/liquids, high humid-
ity, or excessive heat or cold.
Uncrating and Inspecting the Analyzer
The analyzer, along with its associated sample system, is shipped pre-
mounted on unistruts (or on a backpan) either alone in a crate or in a
crated weatherproof shelter. The Optical Bench Assembly is shipped in a
separate box within the Analyzer crate.
Upon receiving the analyzer system, remove the shipping crate and check
the exterior of the shelter and/or analyzer for damage. Remove the Opti-
cal Bench Assembly from its box and check it for any physical damage. Re-
place the Optical Bench Assembly in its box until it is ready to be installed.
Open the shelter and/or analyzer and check to ensure that all of the com-
ponents within are secure and that there is no physical damage. Check
that all of the components and wiring within the Electronics Enclosure
and Oven/Sample System Enclosure are secure and that there is no physi-
cal damage.
After the inspection, close and secure all doors with at least one latch.
This will keep the electronics equipment secure and will prevent dam-
age to the doors and electronic components during installation.
For non-shelter systems, avoid damaging the analyzer piping or
instrumentation by lifting it out of its shipping crate using only its
unistruts or backpan, or metal enclosure. DO NOT use any external
instrument or tubing connectors as a handle for lifting.
The analyzer (on unistruts) weighs approximately 74 kg (163 lb) to
100 kg (220 lb), depending on the system. Use caution when lifting it
from its crate.
!
CAUTION
!
CAUTION
!
WARNING
