Essential Health & Safety Requirements | 23
Installing the Mechanical Components
Do not mount the Optical Bench Assembly in the Electronics En-
closure until after the analyzer has been mounted in its designated
location.
Mounting the Analyzer
The analyzer system comes mounted on a backpan.
Figure 4 illustrates the mounting hole locations and dimensions, plus nec-
essary clearances on all sides.
While installing the mechanical components, refer to customer-specific
drawings for your analyzer. These drawings are located in the “Supple-
mental Information” tab of this manual and the Documentation Package
shipped with the analyzer.
Location and Environment
The IPS-4 Analyzer is designed for operation in environments classified
“Pollution Degree 2” per IEC 61010, so it must be shielded from conduc-
tive pollution and subject to only temporary condensation.
The entire analyzer system can be mounted directly on a wall, in a spe-
cially designed cabinet, or in a custom-built shelter. With its IP65 / NEMA
4 rating, the analyzer system is also suitable for installation in outdoor
locations.
Regardless of which installation method is used, be sure to install the
analyzer in a vibration-free location, and as close as possible to the
sample extraction point to minimize the amount of sample lag time.
The minimum allowable clearances are (if possible, provide extra room to
allow sufficient access for servicing the analyzer). See Figure 4:
Below: 610 mm (24”)
Front: 762 mm (30”) – door swing clearance
Oven/Sample System side: 762 mm (30”) – door swing clearance
Electronics Enclosure side: 457 mm (18”) – door swing clearance
NOTE
NOTE
