Essential Health & Safety Requirements | 37
Terminate the signal and alarm relay contact wires as detailed in the
Customer Connections drawing.
3. Route the AC power conductors through the Power cable entry port
and into the Disconnect Enclosure.
Terminate the AC power wires as detailed in the Customer Connec-
tions drawing.
Do not apply power to the system until after all of the wiring has been
installed, connected, and verified, and only if the purging system (if
used) is ready for operation.
4. Plug all unused cable entry ports with certified plugs.
Permanent Ethernet Cable Connections (Optional)
When using the Ethernet interface on the analyzer, the minimum re-
quirements for the Ethernet cable is a CAT 5e (maximum 100 m) cable to
connect the analyzer to the network, up to a maximum of 100 m from
the hub. For outdoor analyzer installations, hazardous locations, and/or
lengths greater than 100 m, special requirements may be necessary. Con-
tact your network administrator for information.
For details about setting up Ethernet parameters, refer to “Ethernet Net-
work Screen” in Chapter 4.
To install the customer Ethernet cable:
1. Route the Ethernet cable through one of the Signal cable entry ports
and into the Disconnect Enclosure.
2. Connect the cable to J6.
3. Route the cable to the network connection in the plant and connect it.
NOTE
