20 | IPS-4 Zone1/Analyzer
General Installation Information
Figure 3 illustrates an example of the layout of components within the
IPS-4 Analyzer. The components in the Electronics Enclosure gener-
ally do not change. However, many of the sample system components
in the Oven/Sample System Enclosure in this example illustration are
optional and are configured specifically for the application.
Customer-specific drawings for your analyzer are located in the
“Supplemental Information” tab of this manual and in the Documen-
tation Package shipped with the analyzer.
Tools, Equipment, and Supplies Required for Installation
While installing the analyzer, the following tools, equipment, and supplies
are required:
• Door latchkeys (two keys are supplied with the analyzer), attached to
the exterior of the analyzer.
• Set of open-end wrenches for fittings and set of metric ball drivers.
• Wire Cutters, strippers, and crimpers.
• Flat blade instrument screwdriver.
• Soft, non-abrasive cloth.
• Wrist Strap (for grounding).
• Detergent-based leak detector (Snoop
®
or another suitable leak detec-
tion agent is permissible).
• Ethernet cable (supplied by customer), for systems using a permanent
Ethernet connection. Length will vary, depending on application.
Minimum requirements: CAT 5e (maximum 100 m).
Special requirements may be necessary for outdoor analyzer installa-
tions, hazardous locations, and/or lengths greater than 100 m.
Systems using Ethernet also require a ferrite core (supplied by AM-
ETEK).
For systems using a temporary Ethernet connection, a crossover cable
must be used.
• One power-disconnect switch (breaker), rated for at least 250 VAC,
20 A. For safety reasons during maintenance, this switch allows the
main AC power to be disconnected from the analyzer. Supplied by
customer.
• A supply of 1/4” O.D. 316 stainless steel tubing for the Instrument
Air (or N
2
) and Span fluid lines. Length will vary, depending on the
distance between the analyzer and the supply source. Supplied by the
customer.
NOTE
