Essential Health & Safety Requirements | 29
Installing the Sample System
Sample systems will vary for each application, depending on the hazard-
ous location, whether the application is gas or liquid, heated or non-heat-
ed, etc. Sample system components can include, but are not limited to:
• Sample probe (or process tap)
• Sample/vent lines
• Filters
• Sample transport method
• Visual flow indicators (or meters)
• Span, Zero, Sample valves
If your application uses any of these or other special-requirement sample
system components, the customer-specific drawings and Manual Supple-
ments – that describe and illustrate installation, operation (if applicable),
and maintenance (if applicable) – will be included in the “Supplemental
Information” tab of this manual and the Documentation Package shipped
with the analyzer.
All regulatory agency, personnel safety procedures, and installation/
removal procedures must be followed during the installation/removal
of the sample system components. A breathing apparatus must be
worn when installing/removing equipment from the extraction point.
The sample stream may be under positive pressure, and injury or
death from inhaling toxic gases/liquids in the stream could result from
attempting to install/remove equipment without the use of a breathing
apparatus.
Installing the Sample Probe/Sample Tap
If the Sample Probe is supplied by AMETEK, refer to customer-specific
drawings in the “Supplemental Information” tab of this manual or the
Documentation Package shipped with the analyzer for installation infor-
mation. If the Sample Probe/Sample Tap is not supplied by AMETEK, refer
to the information and drawings shipped with the probe.
!
WARNING
