Essential Health & Safety Requirements | 49
Manually Zeroing the Analyzer Sample System
The Zero function forces the analyzer to purge the sample system with a
Zero fluid to remove any residual contaminants in the sample system.
For heated systems, all temperature zones must be at their operating set
points before performing a Zero. If necessary, view the temperature zones
to verify this.
Pressing CANCEL at any time during this procedure will abort the
procedure and return the software to the HOME screen.
To manually zero the analyzer:
1. Ensure that the Zero fluid cylinder (Instrument Air or Nitrogen) is
connected and turned on.
2. Press the SETUP soft key to display the SETUP menu. Select the Cali-
bration Control sub-menu and press enter. Scroll down to the Cali-
bration sub-menu and press enter to display the Calibration screen.
3. Use the DOWN arrow key to select Start zero calibration and press EN-
TER to purge the sample system with Zero fluid. The message “Please
wait ...” will appear while the analyzer performs the calibration func-
tion.
Run the zero for 10 minutes.
Typically, the IPS-4 Analyzer controls the zero flow rate; no adjust-
ments are required.
If the customer provides the sample system zero, run the manual zero
at a flow rate of 2.5 L/minute (0.08 scfm).
4. From the Calibration screen, select Start measure and press ENTER to
return the analyzer to Measure mode.
5. Press the HOME soft key to return to the HOME screen.
6. Turn off the Zero fluid.
The zero is complete and the analyzer is now on-line.
NOTE
NOTE
