– 0.01° resolution.

Press
to accept the new setting and return to the
temperature resolution menu.
Setting the max. SET temperature

Press
to select Max. SET temperature.

Press
. A cursor appears in the Max. SET temperature
value.

Use the numeric keys to enter a new value, or press
to
edit the existing value.

Press
to accept the new setting and return to the Max.
SET temperature menu.
Converting electrical inputs to temperatures

Press
to select the Conversion to temperatures menu.
F3F2 F4 F5F1
Setting voltage or current input conversions from the electric
signal to a temperature reading.

Press a function soft key (
– ) to select the type of
input.

Press a function soft key to select a parameter and start the
editor.
– Low input (voltage or current).
