10. APPENDIX A: SPECIFICATIONS
10.1 UPS-17202-53R Specifications 2000 VA High V oltage
Specification
UPS-17202-53R
Power Rating
2000 VA / 1800 W
Topology
On-Line Double Conversion
Heat Dissipation (BTU/Hour)
1000 at 100% Load
Input Voltage (Nominal)
Range
200-240 VAC
180-300 VAC
Input Frequency
50/60 Hz ±4
(Auto Sense on Start-Up)
Input Power Factor
> 0.95
Input Current THD
< 9.0%
Efficiency
> 86.0%
Output Voltage
208 VAC (Default)
200/220/230/240 VAC (Selectable)
Output Current
9.6 A (Default)
10.9/9.1/8.7/8.3 A (Selectable)
Voltage Regulation
±1.0%
Overload
Online Mode
100-105%: Continuous; Warning Only
105-130%: 2 Minutes
130-200%: 10 Seconds
> 200%: 250 Milliseconds
Overload
Battery Mode
100-105%: Continuous; Warning Only
105-130%: 10 Seconds
>130%: 250 Milliseconds
Overload
Bypass Mode
100-110%: Continuous; Warning Only
110-120%: 30 Minutes
120-130%: 10 Minutes
> 130%: 1 Minute
Battery Voltage (Float / Nominal)
54.7/48.0 VDC
Charger Current
1.0 A
Backup Time (Full Load)
> 3.6 Minutes
Communications Interface
USB / RS-232
Shipping Weight
60.0 lbs. / 27.3 kg.
