10.3 Extension Battery Cabinets
Specification
UPS-BPX-2000
UPS Model
UPS-17202-53R
Voltage (Nominal)
48.0 VDC
Battery Type
12V Flame Retardant Sealed Lead-Acid
Battery Quantity
4 x 2 Strings
Recharge Time
24 Hours (Single Battery, 1A Charger)
Length
17.25 in / 438 mm
Height
3.39 in / 86 mm
Depth
20.20 in / 513 mm
Unit Weight
65.0 lbs. / 29.5 kg
Shipping Weight
75.5 lbs. / 34.3 kg
Safety Agencies
UL1778 cUL to CSA22.2 No. 107.1
UPS-17202-53R Typical run times with external battery cabinets
Percent
Capacity
Watts
Number of Battery Cabinets
Internal
INT+1 EXT
INT+2 EXT
INT+3 EXT
INT+4 EXT
Runtimes are expressed in minutes
Typical runtimes based on fully charged, new batteries, operating under typical load conditions
Times estimated assuming a switch mode power supply
Runtimes are affected by batter age, ambient temperature, site specific usage
patterns and
load conditions
0
0
517
> 16 hrs.
> 16 hrs.
> 16 hrs.
> 16 hrs.
10
160
60
267
532
836
> 16 hrs.
20
320
27
121
242
380
533
30
480
16
74
147
232
325
40
640
11
52
103
162
227
50
800
8.9
39
77
122
171
60
960
7.0
31
61
96
135
70
1260
5.7
25
50
79
111
80
1280
4.8
21
42
66
93
90
1440
4.1
18
36
57
80
100
1600
3.6
16
31
49
69
