PC Congurator Software | A-13
Calibration Button
Use the Calibration Menu to configure the sensor for calibration, perform
the calibration, and view the calibration history.
TABS OPTIONS
CALIBRATION
Set gases to calibrate. Set gas values
and timers. Perform a manual calibra-
tion now.
CALIBRATION HISTORY Plots the history of gases calibrated.
AUTO CALIBRATION
CONFIGURATION
Set time and frequency for Auto Cal.*
CALIBRATION GAS VALUES
Set values and timers for calibration
gases to perform a manual calibration at
a later time.
* Automatic calibration requires a factory-provided remote calibration unit (RCU)
that automatically switches the calibration gases.
All measurements require a two-point calibration: span and zero, so
the zero will always be performed.
Calibrations are only allowed when the sensor is in Normal mode.
Check the Status bar at the bottom of the Home screen if you are
unsure.
All gases selected under Sensor Configuration (O
2
, combustibles, meth-
ane) require calibration but do not have to be calibrated at the same time.
However, calibration will always occur in the same sequence.
1. O
2
Span
2. Zero
3. Combustibles Span
4. Methane Span
To Next Page
