www.amgmicro.com 33
EVOS
fl
User Guide
REV B Published 20 SEP 2010
TROUBLESHOOTING
MECHANICAL ISSUES
PROBLEM POSSIBLE SOLUTIONS
LED light cube selection lever
does not move
NEVER force lever!
Remove LED light cube lock and replace with light cube access cover (see p. 5).
Mechanical stage does not move
Remove stage lock pin.
Check stage brakes (on the stage knobs) and loosen as needed.
Vessel does not sit securely on
moving stage
Use the correct vessel holder for the application (refer to the EVOS Vessel Holders spec
sheet, included on the USB flash drive).
Mechanical stage drifts during
time lapse sessions
Tighten the stage brakes (on the stage knobs) securely before starting a time lapse session
(see p. 16).
Mechanical stage tension is loose
Tighten the stage brakes (on the stage knobs) as desired to increase tension.
Note: For additional technical support, contact your local EVOS distributor. If you do not have your distributor information,
you can look it up at the AMG website or contact AMG Customer Service (see p. 34).
