AMLOGIC S905D3 - Page 24

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
19
Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
AC_8 DO - DDR PHY address/command/control signal
bit 8
VDDQ NC
AC_9 DO - DDR PHY address/command/control signal
bit 9
VDDQ NC
AC_10 DO - DDR PHY address/command/control signal
bit 10
VDDQ NC
AC_11 DO - DDR PHY address/command/control signal
bit 11
VDDQ NC
AC_12 DO - DDR PHY address/command/control signal
bit 12
VDDQ NC
AC_13 DO - DDR PHY address/command/control signal
bit 13
VDDQ NC
AC_14 DO - DDR PHY address/command/control signal
bit 14
VDDQ NC
AC_15 DO - DDR PHY address/command/control signal
bit 15
VDDQ NC
AC_16 DO - DDR PHY address/command/control signal
bit 16
VDDQ NC
AC_17 DO - DDR PHY address/command/control signal
bit 17
VDDQ NC
AC_18 DO - DDR PHY address/command/control signal
bit 18
VDDQ NC
AC_20 DO - DDR PHY address/command/control signal
bit 20
VDDQ NC
AC_21 DO - DDR PHY address/command/control signal
bit 21
VDDQ NC
AC_22 DO - DDR PHY address/command/control signal
bit 22
VDDQ NC
AC_23 DO - DDR PHY address/command/control signal
bit 23
VDDQ NC
AC_24 DO - DDR PHY address/command/control signal
bit 24
VDDQ NC
AC_25 DO - DDR PHY address/command/control signal
bit 25
VDDQ NC
AC_26 DO - DDR PHY address/command/control signal
bit 26
VDDQ NC
AC_28 DO - DDR PHY address/command/control signal
bit 28
VDDQ NC
AC_29 DO - DDR PHY address/command/control signal
bit 29
VDDQ NC
AC_30 DO - DDR PHY address/command/control signal
bit 30
VDDQ NC
AC_31 DO - DDR PHY address/command/control signal
bit 31
VDDQ NC
AC_32 DO - DDR PHY address/command/control signal
bit 32
VDDQ NC
AC_33 DO - DDR PHY address/command/control signal
bit 33
VDDQ NC
