AMLOGIC S905D3 - 4.4 Pin Multiplexing Tables

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
20
Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
AC_34 DO - DDR PHY address/command/control signal
bit 34
VDDQ NC
AC_35 DO - DDR PHY address/command/control signal
bit 35
VDDQ NC
AC_36 DO - DDR PHY address/command/control signal
bit 36
VDDQ NC
AC_37 DO - DDR PHY address/command/control signal
bit 37
VDDQ NC
AC_38 DO - DDR PHY address/command/control signal
bit 38
VDDQ NC
DDR_RSTn DO - DDR3/DDR4/LPDDR4 RSTn VDDQ NC
DDR_DQ0 DIO - DRAM data bus bit 0 VDDQ To
DRAM
DDR_DQ1 DIO - DRAM data bus bit 1 VDDQ To
DRAM
DDR_DQ2 DIO - DRAM data bus bit 2 VDDQ To
DRAM
DDR_DQ3 DIO - DRAM data bus bit 3 VDDQ To
DRAM
DDR_DQ4 DIO - DRAM data bus bit 4 VDDQ To
DRAM
DDR_DQ5 DIO - DRAM data bus bit 5 VDDQ To
DRAM
DDR_DQ6 DIO - DRAM data bus bit 6 VDDQ To
DRAM
DDR_DQ7 DIO - DRAM data bus bit 7 VDDQ To
DRAM
DDR_DQ8 DIO - DRAM data bus bit 8 VDDQ To
DRAM
DDR_DQ9 DIO - DRAM data bus bit 9 VDDQ To
DRAM
DDR_DQ10 DIO - DRAM data bus bit 10 VDDQ To
DRAM
DDR_DQ11 DIO - DRAM data bus bit 11 VDDQ To
DRAM
DDR_DQ12 DIO - DRAM data bus bit 12 VDDQ To
DRAM
DDR_DQ13 DIO - DRAM data bus bit 13 VDDQ To
DRAM
DDR_DQ14 DIO - DRAM data bus bit 14 VDDQ To
DRAM
DDR_DQ15 DIO - DRAM data bus bit 15 VDDQ To
DRAM
DDR_DQ16 DIO - DRAM data bus bit 16 VDDQ NC
DDR_DQ17 DIO - DRAM data bus bit 17 VDDQ NC
DDR_DQ18 DIO - DRAM data bus bit 18 VDDQ NC
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
