Signal Name Type Description
UART_EE _C_CTS DI UART Port C Clear To Send Signal in EE domain
UART_EE _C_RTS DO UART Port C Ready To Send Signal in EE domain
Table 4-15 ISO7816 Interface Signal Description
Signal Name Type Description
ISO7816_DATA DIO ISO7816 data signal
ISO7816_CLK DO ISO7816 clock signal
Table 4-16 TS In Interface Signal Description
Signal Name Type Description
TSIN_A_DIN0 DI Serial TS input port A data
TSIN_A_CLK DI TS input port A clock
TSIN_A_SOP DI TS input port A start of stream signal
TSIN_A_VALID DI TS input port A date valid signal
TSIN_B_DIN0 DI Serial/Parallel TS input port B data 0
TSIN_B_DIN1 DI Parallel TS input port B data 1
TSIN_B_DIN2 DI Parallel TS input port B data 2
TSIN_B_DIN3 DI Parallel TS input port B data 3
TSIN_B_DIN4 DI Parallel TS input port B data 4
TSIN_B_DIN5 DI Parallel TS input port B data 5
TSIN_B_DIN6 DI Parallel TS input port B data 6
TSIN_B_DIN7 DI Parallel TS input port B data 7
TSIN_B_FAIL DI TS input port B fail signal
TSIN_B_CLK DI TS input port B clock
TSIN_B_SOP DI TS input port B start of stream signal
TSIN_B_VALID DI TS input port B date valid signal
Table 4-17 PWM Interface Signal Description
Signal Name Type Description
PWM_A DO PWM channel A output signal
PWM_B DO PWM channel B output signal
PWM_C DO PWM channel C output signal
PWM_D DO PWM channel D output signal
PWM_E DO PWM channel E output signal
PWM_F DO PWM channel F output signal
PWMAO_A / PWMAO_A_
HIZ
DO PWM A output signal in Always On domain, or extended HiZ
function of PWMAO_A
