AMLOGIC S905D3 - 5.7.4 SPICC Timing Specification

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
48
Figure 5-3 EMMC HS200 Data Output Timing
Table 5-3 HS200 Timing Specification
Symbol Parameter Min Max Unit
tPERIOD Cycle time data
transfer mode
5 - ns
tISU output set-up time 1.4 - ns
tIH output hold time 0.8 - ns
Figure 5-4 EMMC HS400 Data Intput Timing
S905D3 Quick Reference Manual 5 Operating Conditions
Preliminary Version
Confidential for Wesion!
