Transmitter (slave mode)
Symbol Parameter Min Typ Max unit
tHC High level of
SCLK
0.4 T
tLC Low level of
SCLK
0.4 T
tRC Edge time of
SCLK
0.8 ns
tsu in Setup time of
WS/Din
4 ns
thd in Hold time of WS/
Din
4 ns
tdly Delay between
SCLK and Dout
2 12 15 ns
Note
Measure Pointrefers to VIH, ViL parameter of Normal GPIO Specifications.
