Tango Series Audio Controllers
Product Specifications
The following table provides technical specifications for the Tango Audio Controllers. Unless otherwise
noted, these specifications apply to both the DAS-T0804-SIG and DAS-T0808-SIG models.
Tango Audio Controllers Product Specifications
Models Available: • DAS-T0804-SIG Tango 8-Source, 4-Zone Audio Controller (FG1103-01)
• DAS-T0808-SIG Tango 8-Source, 8-Zone Audio Controller (FG1103-02)
Stereo Output: 25 Watts/CH stereo (20Hz to 20Khz @ .1% THD)
Power: 960W max (Actual average usage = 300W)
Zone Support: DAS-T0804-SIG - Four independent audio Zones.
DAS-T0808-SIG - Eight independent audio Zones.
• Each Zone is protected thermally.
• Zone grouping.
• Independent Volume, Bass, Treble, Balance and SRS
®
controls in each
zone.
Stereo Amplifiers: • 40 Watts/CH stereo amplifiers (20Hz to 20Khz @ .1% THD).
• Amplifiers are protected from overload and thermal runaway.
SRS/WOW
®
: Standard SRS/WOW
®
audio enhancement technology by SRS Labs, on all
zones.
Note: SRS/WOW is a registered trademark of SRS labs, Inc.
Front Panel Components:
• Light Bar Blue light bar indicates power status.
• LEDs Blue LEDs indicate level status.
• Function/Navigation Buttons 5 pushbuttons allow for front panel programming, selection of sources, tun-
ing AM/FM radio stations, or Sirius satellite radio stations (when equipped
with the optional Sirius and/or AM/FM Tuner Card).
• IR Receiver This is where you must aim the remotes from your audio source components
so the Controller can learn and emulate those commands.
• LCD Display Displays information necessary during the programming steps and afterward
is the display to indicate information about the source input and zone activity.
Rear Panel Components:
• Power Switch & Receptacle The master power switch will remain in the ON position normally.
• Paging In/Out Ports RCA jacks to connect to Paging devices (any audio input can be used as a
paging device). The Paging device connects to the Controller via the "Paging
In" connector. The “Paging Out” connector is used to carry the page to Zone
Expander(s).
• RJ 45 Port Ethernet Port for future expansion
• RS-232 Port DB9 connector allows the Tango Audio Controller to receive Controller Com-
mand Messages and provide status messages. This port is intended
primarily for troubleshooting purposes.
• AM/FM Antenna Inputs Connections for the AM and FM Antennas.
• Audio Inputs Stereo Inputs, 47K impedance, buffered.
• Audio Outputs Stereo Looping Outputs, buffered.
• IR Outputs • DAS-T0804-SIG: Four IR 3.5mm mono output jacks.
• DAS-T0808-SIG: Eight IR 3.5mm mono output jacks.
• Zone Outputs • DAS-T0804-SIG: 4 zone output connectors (connect to Metreau keypads)
• DAS-T0808-SIG: 8 zone output connectors (connect to Metreau keypads)
• Expansion Port RJ-11 Port connects main Tango Controller with Tango Zone Expanders.
Dimensions (HWD):
(including feet)
• 4" x 17" x 13.5"
• 10.16 cm x 43.18 cm x 34.29 cm
