Installation
16
Tango Series Audio Controllers
DAS-T0808-SIG (8-Zone Controller)
Use the following table when connecting to DAS-T0808-SIG (8-Zone Controller):
DAS-T0804-SIG (4-Zone Controller)
Use the following table when connecting to DAS-T0804-SIG (4-Zone Controller):
On-Board AM/FM Tuner Module
Tango Controllers come equipped with one DAS-AMFM AM/FM Tuner Module (FG1110-01).
Additionally, you can install a second Tuner Module, as an optional accessory.
The Tuner Modules take up the first (and second if two Tuner Modules are installed) source input on the
Tango Controller.
Each source component is selected using the appropriate button on the keypad, remote or other interface
which corresponds to one of the Tango Controller’s audio device inputs (labeled as: input 1, input 2, and
input 3 respectively).
Zone Expander Addressing - Connected to DAS-T0808-SIG (8-Zone Controller)
Zone Expander # DAS-T0804X-SIG (4 Zones) DAS-T0804X-SIG (8 Zones)
Zone Expander 1 Zones 9 – 12: set to Address 1 Zones 9 – 16: set to Address 1
Zone Expander 2 Zones 13 – 16: set to Address 2 Zones 17 – 24: set to Address 2
Zone Expander 3 Zones 17 – 20: set to Address 3 Zones 25 – 32: set to Address 3
Zone Expander 4 Zones 21 – 24: set to Address 4 Zones 33 – 40: set to Address 4
Zone Expander 5 Zones 25 – 28: set to Address 5 Zones 41 – 48: set to Address 5
Zone Expander 6 Zones 29 – 32: set to Address 6 Zones 49 – 56: set to Address 6
Zone Expander 7 Zones 33 – 36: set to Address 7 Zones 57 – 64: set to Address 7
Zone Expander Addressing - Connected to DAS-T0804-SIG (4-Zone Controller)
Zone Expander # DAS-T0804X-SIG (4 Zones) DAS-T0804X-SIG (8 Zones)
Zone Expander 1 Zones 5 – 8: set to Address 1 Zones 5 – 12: set to Address 1
Zone Expander 2 Zones 9 – 12: set to Address 2 Zones 13 – 20: set to Address 2
Zone Expander 3 Zones 13 – 16: set to Address 3 Zones 21 – 28: set to Address 3
Zone Expander 4 Zones 17 – 20: set to Address 4 Zones 29 – 36: set to Address 4
Zone Expander 5 Zones 21 – 24: set to Address 5 Zones 37 – 44: set to Address 5
Zone Expander 6 Zones 25 – 28: set to Address 6 Zones 45 – 52: set to Address 6
Zone Expander 7 Zones 29 – 32: set to Address 7 Zones 53 – 60: set to Address 7
Refer to the DAS-AMFM Installation Guide for detailed installation instructions.
Just as a radio is incapable of playing two different stations at the same time, if
multiple zones are listening to the same source, they will be listening to the same
music. Consider multiple components of the same type (such as the tuner) if different
zones wish to listen to different radio stations at the same time.
