Installation
20
Tango Series Audio Controllers
Specifications
MIO R-1 AUDIO Specifications
Power Requirements: 4 AAA Alkaline Batteries (included) - approx. 5 hours battery life
Transmission
Frequencies
AMX 38 KHz/455 KHz IR
Note: The Metreau MET-6N keypads only support 38 KHz. When used with MET-6N
keypads, the MIO R-1 AUDIO must be set to 38 KHz.
Transmission
Range (distance)
with MIO IR Receiver
• 100 feet at 38KHz
• 50 feet at 455KHz
Transmission
Range (angle)
• 140 degrees (+/-70° from perpendicular) horizontally from an axis extending from
the end of the remote.
• 40 degrees (+/-20° from perpendicular) vertically from an axis extending from the
end of the remote.
Top Components • LED - blue backlit buttons indicate device is awake
• Display (OLED) - 128 x 32 pixels, active area is 29.42mm x 7.98mm
• Pushbuttons - the power button is red backlit; the rest are blue backlit buttons. 45
buttons; 9 custom buttons (3 macro and 6 device).
Rear Component • Programming Port - 2.5 mm stereo female conductor jack
• Battery Door
Dimensions (HWD) 9.50 x 2.00 x .74 (241.3 mm x 50.8 mm x 18.80 mm)
Weight • .45 lbs (20 kg) without batteries
• .55 lbs (25 kg) with batteries
Operating Environment: • Operating Temperature: 0° to 50° C (32° to 122° F)
• Storage Temperature: -10° to 70° C (14° to 158° F)
Included Accessories: • 4 AAA Batteries
Other AMX Equipment • DB-9 extension cable (FG10-727)
• Programming Cable - a 3 wire, 2.5 mm stereo jack (FG10-817)
• Custom engraving (FG147-01)
• MIO-RCC Kit (FG147-03K)
• MIO-RCC Charging Base (FG147-02)
• MIO-RBP Rechargeable Lithium Ion Battery (FG147-10)
• MIO Modero IR Receiver (FG5797-01xx; xx indicates color)
