Appendix B - Commands / Messages
55
Tango Series Audio Controllers
Appendix B - Commands / Messages
This section provides reference information for the following:
RS-232 Controller Command Messages - These commands can be sent directly to the Tango
Audio Controller via the RS-232 (DB9) port on the rear panel. See the Connecting the RS-232
Serial Port section on page 17 for connection and DB9 cabling information.
Tango Audio Controller Status Messages (page 62) - These messages are received via the
RS-232 port, and are used primarily for troubleshooting purposes.
Source Command Codes (page 67) - Source Command Codes, received from the SWT
keypads are referenced here by Source Type and Command Index.
Sirius Status Codes (page 68) - Status Codes received from the (optional) DAS-SIRIUS Sirius
Satellite Radio Tuner Module are described here.
RS-232 Controller Command Messages
RS-232 Controller Command Messages
MVER Get Firmware Version Firmware Status Version
- or -
ERR
MGCF Get Configuration Configuration Status
- or -
ERR
FNIC Get Number of IIC devices Num IIC Devices Status
- or -
ERR
FGICx Get IIC Device Status, where:
‘x’ is the IIC device index, valid values range from 1 to the
number of available IIC devices as reported in the ‘Num IIC
Devices Status’
IIC Device Status
- or -
ERR
AMX AMX Beacon Poll AMX Beacon Response
- or -
ERR
MGBD Get Baud Rate Baud Rate Status
- or -
ERR
BDHI Set Baud Rate to 9600 Baud Rate Status
- or -
ERR
BDLO Set Baud Rate to 4800 Baud Rate Status
- or -
ERR
MSVLr,v Set Volume, where:
•‘r’ is the desired room, (1-64)
•‘v’ is the desired volume level, valid values are:
101: Mute
0....70: 0....-70 dB
Volume Status
- or -
ERR
MGVLr Get Volume, where:
‘r’ is the desired room, (1-64)
Volume Status
- or -
ERR
