Setup and Configuration
40
Tango Series Audio Controllers
Learn IR Commands
Refer to the Appendix A: IR Commands By Source Type section on page 51 for details.
1. Select Learn IR on the Select Source # Type screen (FIG. 29) to access the Learn IR screen
(FIG. 30), with the first IR to be learned for the selected Source Type:
2. Hold the remote approx. 6" - 12” away from the Controller.
3. Point the remote at the IR window.
4. Press and hold the button for 2 seconds on the remote that corresponds to the IR function displayed.
If the IR displayed is not used by the Source Remote, select Next to move to the next IR to be
learned
5. The Programming screen will display one of the following messages, indicating the accuracy of the
IR code received (FIG. 31):
FIG. 30 Learn IR Commands
Returns to the Select Source # Type scre
Clears the current IR code
Next IR code
Previous IR code
Status of IR
“Clear” is used to clear an IR that has been previously learned.
Only learn the IR codes that apply to the particular Source Remote.
FIG. 31 IR Commands - Messages
