Appendix B - Commands / Messages
59
Tango Series Audio Controllers
RS-232 Controller Command Messages (Cont.)
MSRGs,b8,b7,
b6,b5,b4,b3,
b2,b1
Create Room Grouping, where:
• ‘s’ is the source which to associate the rooms, (1-8)
• ‘b8’.... ‘b1’ is a binary room selection bitmap where all rooms to
be grouped have a binary 1 in the room position. The most
significant bit in ‘b8’ is for room 64 and the least significant bit in
‘b1’ is for room 1.
Notes:
A room grouping will be considered invalid if there are not at least
two rooms selected for the group.
Only one room group can be associated with any given source.
Example:
MSRG,1,0,0,0,0,0,0,0,37
Groups zones 1, 3, and 6 to source 1.
Note: The number 37 is calculated by applying a binary mask on
the bits to be grouped.
• Zone 1 represents the Least Significant Bit and zone 8, the MSB.
• The binary bitmask for 1,3, and 6 is 0010 0101 which is 37 in
decimal.
Room Grouping Status
- or -
ERR
MARGgg,r Add Room to Group, where:
•‘g’ is any room already in the group, (1-64)
• ‘r’ is the room, (1-64)
Room Grouping Status
- or -
ERR
MRRGr Remove Room from Group, where:
‘r’ is the room to remove, (1-64)
Note: The Room Grouping will be removed if less than 2 rooms
are associated with the given source.
Room Grouping Status
- or -
ERR
MDRG Dissolve all Room Groupings ACK
- or -
ERR
MGRGr Get Room Grouping, where:
‘r’ is any room in the grouping, (1-64)
Room Grouping Status
- or -
ERR
MIGVr,i Increment the Volume for a Room Grouping, where:
• ‘r’ is any room in the grouping, (1-64)
• ‘i’ is the increment value or 0 for system default
ACK
- or -
ERR
MDGVr,i Decrement the Volume for a Room Grouping, where:
• ‘r’ is any room in the grouping
• ‘i’ is the decrement value or 0 for system default
ACK
- or -
ERR
MSGVr,v Set the Volume for a Room Grouping, where:
•’r’ is any room in the grouping
•‘v’ is the desired volume level, valid values are:
101: Mute
0...55: 0...-55 dB
ACK
- or -
ERR
MGRSs Get the Rooms currently listening to a source, where:
‘s’ is the desired source, (1-8)
Source Grouping Status
- or -
ERR
MSFVr,s,f Set the favorite, where:
•‘r’ is the desired room, (1-64)
•‘s
’ is the desired source, (1-8)
•‘f’ is the direct tuning string; it can be from 0 to 7 characters long
and is translated as specified in the ‘Send Source Direct Data’
command: Zero length data will clear the favorite.
Favorite Status
- or -
ERR
