AMX MIO-R4 Instruction Manual

Programming the Mio R-4
32
Mio Modero R-4 Remote
Fixed Fonts and ID Numbers
Font styles can be used to program the text fonts on buttons, sliders, and pages. The following chart shows the default
font type and their respective ID numbers generated by TPDesign4.
Slider/Cursor Names
RGB Values for all 88 Basic Colors (Cont.)
Index No. Name Red Green Blue
83 Grey13 34 34 34
84 Grey2 221 221 221
85 Grey11 68 68 68
86 Grey14 17 17 17
87 Black 0 0 0
255 TRANSPARENT 99 53 99
Fixed Fonts and ID Numbers
Font ID
#
Font type Size Font ID
#
Font type Size
1 Courier New 9 19 Arial 9
2 Courier New 12 20 Arial 10
3 Courier New 18 21 Arial 12
4 Courier New 26 22 Arial 14
5 Courier New 32 23 Arial 16
6 Courier New 18 24 Arial 18
7 Courier New 26 25 Arial 20
8 Courier New 34 26 Arial 24
9 AMX Bold 14 27 Arial 36
10 AMX Bold 20 28 Arial Bold 10
11 AMX Bold 36 29 Arial Bold 8
32 - Variable Fonts start at 32.
You must import fonts into a TPDesign4 project file. The font ID numbers are
assigned by TPDesign4. These values are also listed in the Generate
Programmer’s Report.
Slider/Cursor Names
Bargraph Slider Names Joystick Cursor Names
None None
Ball Arrow
Circle -L Ball
Circle -M Circle
Circle -S Crosshairs
Precision Gunsight
Rectangle -L Hand
Rectangle -M Metal
Rectangle -S Spiral
Smart Button Bubbled - L Smart Button Bubbled
Smart Button Bubbled - S Target
Windows View Finder
Windows Active

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
