Programming the Mio R-4
52
Mio Modero R-4 Remote
"^" Button Commands (Cont.)
^JSB Set bitmap/picture alignment using a numeric keypad layout for those buttons with a defined address range.The
alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of
the button.
Syntax:
"'^JSB-<vt addr range>,<button states range>,<new text alignment>'"
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and
2 = On state).
• new text alignment = Value of 1- 9 corresponds to the following locations:
Example:
SEND_COMMAND Device,"'^JSB-500.504&510.515,1&2,1'"
Sets the off/on state picture alignment to upper left corner for those buttons with variable text ranges of 500-504
& 510-515.
^JSI Set icon alignment using a numeric keypad layout for those buttons with a defined address range. The
alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of
the button.
Syntax:
"'^JSI-<vt addr range>,<button states range>,<new icon alignment>'"
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and
2 = On state).
• new icon alignment = Value of 1 - 9 corresponds to the following locations:
Example:
SEND_COMMAND Device,"'^JSI-500.504&510.515,1&2,1'"
Sets the Off/On state icon alignment to upper left corner for those buttons with variable text range of 500-504 &
510-515.
^JST Set text alignment using a numeric keypad layout for those buttons with a defined address range. The
alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of
the button.
Syntax:
"'^JST-<vt addr range>,<button states range>,<new text alignment>'"
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and
2 = On state).
• new text alignment = Value of 1 - 9 corresponds to the following locations:
Example:
SEND_COMMAND Device,"'^JST-500.504&510.515,1&2,1'"
Sets the text alignment to the upper left corner for those buttons with variable text ranges of 500-504 & 510-
515.
1
4
7
8
9
6
3
2
5
0
Zero can be used for an absolute position
1
4
7
8
9
6
3
2
5
0
Zero can be used for an absolute position
1
4
7
8
9
6
3
2
5
0
Zero can be used for an absolute position

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
