AMX MIO-R4 Instruction Manual

Programming the Mio R-4
39
Mio Modero R-4 Remote
Page Commands (Cont.)
@PPN Activate a specific popup page to launch on either a specified page or the current page. If the page name is
empty, the current page is used (see example 2). If the popup page is already on, do not re-draw it. This
command works in the same way as the 'Show Popup' command in TPDesign4.
Syntax:
SEND_COMMAND <DEV>,"'@PPN-<popup page name>;<page name>'"
Variables:
• popup page name = 1 - 50 ASCII characters. Name of the popup page.
• page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On
Example:
SEND_COMMAND Device,"'@PPN-Popup1;Main'"
Activates 'Popup1' on the 'Main' page.
Example 2:
SEND_COMMAND Device,"'@PPN-Popup1'"
Activates the popup page 'Popup1' on the current page.
@PPT Set a specific popup page to timeout within a specified time. Timeout is in 1/10 seconds. If timeout is empty,
popup page will clear the timeout.
Syntax:
SEND_COMMAND <DEV>,"'@PPT-<popup page name>;<timeout>'"
Variables:
• popup page name = 1 - 50 ASCII characters. Name of the popup page.
• timeout = timeout duration in 1/10ths of a second.
Example:
SEND_COMMAND Device,"'@PPT-Popup1;30'"
Sets the popup page 'Popup1' to timeout within 3 seconds.
@PPX Close all popups on all pages. This command works in the same way as the 'Clear All' command in TPDesign4.
Syntax:
SEND_COMMAND <DEV>,"'@PPX'"
Example:
SEND_COMMAND Panel,"'@PPX'"
Close all popups on all pages.
@PSE Set the show effect for the specified popup page to the named show effect.
Syntax:
SEND_COMMAND <DEV>,"'@PSE-<popup page name>;<show effect name>'"
Variables:
• popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.
• show effect name = Refers to the popup effect name being used.
Example:
SEND_COMMAND Device,"'@PSE-Popup1;Slide from Left'"
Sets the Popup1 show effect name to 'Slide from Left'.
@PSP Set the show effect position. Only 1 coordinate is ever needed for an effect, however the command will specify
both. This command sets the location at which the effect will begin at.
Syntax:
SEND_COMMAND <DEV>,"'@PSP-<popup page name>;<x coordinate>,<y coordinate>'"
Variable:
• popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.
Example:
SEND_COMMAND Device,"'@PSP-Popup1;100,0'"
Sets the Popup1 show effect x-coordinate value to 100 and the y-coordinate value to 0.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
