AMX MIO-R4 Instruction Manual

Programming the Mio R-4
66
Mio Modero R-4 Remote
Listboxes
Listboxes provide flexibility to remote pages once constrained by physical display areas. Both static and dynamic tables
can display multiple devices and items when used with proper navigation tools. List Box commands can be used in
conjunction with the application TPDesign4 to create both static and dynamic commands.
Any data field (including primary data) may be enclosed in double quotes so that commas within that data field will not
be interpreted as delimiters. Within the double quotes in such a field, the backslash (\) is treated as an escape character so
that double quote literals can still be used within the field. When a backslash is encountered, it is discarded and the
following character is treated as a literal. This meansthat if a backslash is part of the data field, it needs to be escaped
with a preceding backlash as well.
When a column or row number is required as a field in any command, note that the numbering begins at 1, not 0 (i.e. the
first column is column 1 and the first row is row 1).
There are no hard limits enforced for the number of list boxes and such list box parameters as list address and column
count. The range is determined by available memory, which is affected by things like how many lists are defined and how
many items will be added for each list.
List Box Commands
The Mio R-4 supports Data List Box Commands.
Remote Setup Commands (Cont.)
^PWD Set the page flip password.
Password level is required and must be 1 - 4.
Syntax:
SEND_COMMAND <DEV>,"'^PWD-<password level>,<page flip password>'"
Variables:
• password level = 1 - 4.
• page flip password = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Device,"'^PWD-Main'"
Sets the page flip password on Password Level 1 'Main'.
List Box Commands
Data List Commands
^LDN Creates a new data list. Unique list addresses and names are handled programmatically.
It is up to the program to make sure the list address and name are unique.
Syntax:
"'^LDN-<list port>,<list address>,<column count>,<list name>'"
Variables:
• list port = 1-100. Port where data resides
• list address = address where data resides
• column count = the number of data columns (includes hidden columns)
• list name = User specified name for the data list
Example:
SEND_COMMAND Device, "'^LDN-5,1,4,my songs'"
Creates a data list of 4 columns named "my songs" and places it at port 5, address 1.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
